Petronas Twin Tower 2 Download PDF


Click an image to view larger version.
Height: Occupied
375 m / 1,230 ft

Height: To Tip
451.9 m / 1,483 ft
Height: Architectural
451.9 m / 1,483 ft

Petronas Twin Tower 2 Outline
Height: Observatory
370 m / 1,214 ft
Floors Above Ground
88
Floors Below Ground
5
# of Elevators
39
Top Elevator Speed
7 m/s
Tower GFA
197,500 m² / 2,125,872 ft²

Facts

Official Name Petronas Twin Tower 2
Name of Complex Petronas Towers
Other Names Tower 2, Petronas Twin Tower Kuala Lumpur City Centre, Petronas Tower 2
Structure Type Building
Status Completed
Country Malaysia
City Kuala Lumpur
Street Address & Map Jalan Ampang
Postal Code 50088
Building Function office
Structural Material composite
Construction Start 1992
Completion 1998
Official Website Petronas Twin Towers
Rankings Click arrows to view the next taller/shorter buildings
Global Ranking #11 Tallest in the World
Regional Ranking #8 Tallest in Asia
National Ranking #1 Tallest in Malaysia
City Ranking #1 Tallest in Kuala Lumpur

Companies Involved

Developer KLCC Property Holdings Berhad
Architect
Design Cesar Pelli & Associates
Architect of Record Adamson Associates
Structural Engineer
Design Thornton Tomasetti
Engineer of Record Ranhill Bersekutu Bhd
MEP Engineer
Design WSP Flack + Kurtz
Engineer of Record KTA Tenaga Sdn Bhd
Main Contractor Kukdong Engineering & Construction; Samsung C&T Corporation; Syarikat Jasatera Sdn. Bhd.
Other Consultant
• Fire Rolf Jensen & Associates
• Wind RWDI
Material Supplier
• Construction Hoists Alimak Hek
• Elevator Otis Elevator Company
• Fire Proofing Grace Construction Products
• Sealants Dow Corning Corporation
• Steel Arbed

About Petronas Twin Tower 2

The Petronas Towers, located in Kuala Lumpur, were designed to herald the emergence of Malaysia into the global economy and act as an easily identifiable symbol for the fast-growing country.

The development’s scope, scale, and design reflect the desire to create a representative manifestation of local traditions and ingenuity. In particular, the design is based on Islamic geometry, a reflection of Malaysia’s cultural heritage. The buildings are perhaps most noteworthy for the skybridge that connects them on the 41st and 42nd floors. Although there is no structural benefit to the connection, it offers more than just an architectural flourish. By linking the two buildings together, the facilities of each tower around that level can be shared, including a conference room, prayer room, and executive dining room. Additionally, the skybridge is an integral part of the towers’ fire evacuation strategy.

Due to budgetary constraints, the development timeline of Petronas Towers was constrained to six years, an ambitious feat considering that the original expected construction time for the project was eight years. To speed things along, two construction consortiums were hired, each being responsible for building one of the towers. Naturally, incentives were established that rewarded the first team to the top with the rights to build the skybridge, resulting in a race between the Japanese and South Korean consortiums. Ultimately, Tower 2 was the first to reach its pinnacle, with the South Korean crew claiming victory.

CTBUH Initiatives

Top Company Rankings: The World’s 100 Tallest Buildings
13 Oct 2016 – CTBUH Research

Height: The History of Measuring Tall Buildings
Dec 2009 – CTBUH News

CTBUH / Nakheel Asia Tour Report
19-29 Apr 2007 – Tour Report

Videos

Building Tall Skyscraper Lecture Series: How High Can We Go?
16 Mar 2017 – Antony Wood, CTBUH; Richard Tomasetti, Thornton Tomasetti; Ian Smith, thyssenkrupp, Gordan Gill, Adrain Smill + Gordon Gill Architecture

CTBUH 2016 China Conference - Panel,"Tall Buildings and Context: How High Can We Go and Why Should We?"
18 Oct 2016 – Ron Klemencic, Magnusson Klemencic Associates; Karl Almstead, Turner Construction Company; Andrew Nicholson, CBRE; Jon Pickard, Pickard Chilton; Ian Smith, thyssenkrup

CTBUH Video Interview – Hashimah Hashim
18 Oct 2016 – Hashimah Hashim, KLCC Property Holdings Berhad

More Videos

Videos Related to Petronas Twin Tower 2

Videos Related to Petronas Twin Tower 2

Building Tall Skyscraper Lecture Series: How High Can We Go?
16 Mar 2017 – Building Tall – Skyscraper Lecture Series; Antony Wood, CTBUH; Richard Tomasetti, Thornton Tomasetti; Ian Smith, thyssenkrupp, Gordan Gill, Adrain Smill + Gordon Gill Architecture
Thursday, March 16, 2017. Chicago, United States of America. Hosted in collaboration with the Chicago Architecture Foundation, the first lecture of the series Building…
CTBUH 2016 China Conference - Panel,"Tall Buildings and Context: How High Can We Go and Why Should We?"
18 Oct 2016 – Presentation at CTBUH 2016 China Conference; Ron Klemencic, Magnusson Klemencic Associates; Karl Almstead, Turner Construction Company; Andrew Nicholson, CBRE; Jon Pickard, Pickard Chilton; Ian Smith, thyssenkrup
Tuesday, October 18, 2016. Shenzhen, China. Ron Klemencic, Magnusson Klemencic Associates; Karl Almstead, Turner Construction Company; Andrew Nicholson, CBRE; Jon…
CTBUH Video Interview – Hashimah Hashim
18 Oct 2016 – 2016 China Conference Interviews; Hashimah Hashim, KLCC Property Holdings Berhad
Hashimah Hashim of KLCC Property Holdings Berhad is interviewed by Chris Bentley during the 2016 CTBUH China Conference. Hashimah discusses the master planning and…
CTBUH Video Interview – Jon Pickard
18 Oct 2016 – 2016 China Conference Interviews; Jon Pickard, Pickard Chilton
Jon Pickard of Pickard Chilton is interviewed by Chris Bentley during the 2016 CTBUH China Conference. Jon discusses the local economic impacts of tall buildings.
Mega Size Mixed-Use Projects: Redefining Vertical Urbanism
17 Oct 2016 – Presentation at CTBUH 2016 China Conference; Dennis Poon, Thornton Tomasetti
Monday October 17, 2016. Shenzhen, China. Dennis Poon of Thornton Tomasetti, presents at the 2016 China Conference Session 4c: Structural & Geotechnic Engineering. As…
CTBUH Video Interview – Karl Fender
16 Oct 2016 – Presentation at CTBUH 2016 China Conference; Karl Fender, Fender Katsalidis Architects
Karl Fender of Fender Katsalidis Architects is interviewed by Chris Bentley during the 2016 CTBUH China Conference. Karl discusses the design concept for Merdeka PNB118…
Interview: Faudziah Ibrahim
27 Oct 2015 – 2015 New York Conference Interviews; Faudziah Ibrahim, KLCC
Faudziah Ibrahim of KLCC is interviewed by Chris Bentley during the 2015 CTBUH New York Conference at the Grand Hyatt New York. Faudziah discusses Vision 2020 of Malaysia…
Petronas Towers and KLCC: Urban Catalyst
26 Oct 2015 – Presentation at CTBUH 2015 New York Conference; Faudziah Ibrahim, KLCC Property Holdings Berhad
This presentation examines the role of skyscrapers in a well-planned mixed commercial development that is not driven by speculative short-term investment goals in…
Fazlur R. Khan Lifetime Achievement Award: Wind Engineering the World’s Tallest
6 Nov 2014 – CTBUH "13th Annual Awards"; Dr. Peter Irwin, RWDI Consulting Engineers
Peter Irwin, one of the founding partners of Rowan Williams Davies and Irwin Inc. (RWDI), has led wind engineering on many of the world’s tallest buildings, including the…
Fazlur Khan Lifetime Achievement Medal: Geotechnics for the World’s Tallest
7 Nov 2013 – CTBUH "12th Annual Awards"; Clyde N. Baker, Jr., AECOM
Clyde Baker has performed geotechnical engineering for seven of the 16 tallest buildings in the world, and a major portion of the high-rise buildings built in downtown…
Interview: Fazlur Khan Winner: Clyde Baker
7 Nov 2013 – 2013 Awards Ceremony/Symposium Interviews; Clyde N. Baker, Jr., AECOM
Clyde N. Baker, Jr., Fazlur R. Khan Lifetime Achievement Medal Winner, discusses his lifetime work as a geotechnical engineer including working on 7 of the 16 world's…
Advanced Structural Silicone Glazing
19 Sep 2012 – Presentation at CTBUH 2012 9th World Congress, Shanghai; Lawrence D. Carbary, Industry Scientist; Dow Corning Corporation
This presentation discussed an advanced engineering evaluation using nonlinear analysis to improve structural silicone glazing (SSG) design in high performance curtain…
Founder and First Chairman 'Lynn Beedle'
2 Nov 2008 – CTBUH Leader Presentations & Meetings; CTBUH 2008 Leader Presentation Video
Biography about Lynn Beedle and the Council on Tall Buildings, narrated by his son David and shown during the first annual awards dinner. For his 30 years of dedicated…

Browse hundreds of other videos from Council events including conferences and interviews with prominent tall building professionals in the Video Library

Research Papers

Rethinking Evacuation: Rethinking Cities
Aug 2011 – CTBUH Journal, 2011 Issue III

Structural Design of Reinforced Concrete Tall Buildings
Feb 2010 – CTBUH Journal, 2010 Issue I

Application of High Performance Concrete in Petronas Twin Tower, KLCC
Oct 2004 – CTBUH 2004 Seoul Conference

Other Building Facts

Tallest twin-tower buildings in the world.

Shared world's tallest building title with Petronas Tower 1; 1998 - 2004.
